Product Overview
The SOLARY PS104U rotating bumper paint stand secures a detached plastic bumper for refinishing while allowing access to difficult spray areas. The supplied PS104U sheet confirms 90-degree rotation, five locking positions and a 103–140 cm illustrated height range. Rubber protection covers key contact areas, and four 4-inch industrial swivel casters support movement around the workshop. The specified material thickness is 2.20 mm.
Key Benefits
- Rotate for coating access — The documented 90-degree movement helps expose different bumper surfaces during refinishing preparation.
- Select five locking positions — The locking arrangement provides repeatable positions for repair and spray access; follow the manual for secure engagement.
- Adjust working height — The dimension drawing labels 103–140 cm, allowing different setup heights for the task.
- Protect bumper contact areas — Rubber is specified at key support areas to help reduce damage during careful handling.
- Move on industrial casters — Four 4-inch industrial swivel casters are described; secure and balance the component before moving.
Applications
Use PS104U for detached plastic bumper repair preparation and spray positioning. Confirm attachment points, expected bumper weight and dimensions before ordering. Follow the instructions for mounting, locking and moving the stand, and verify compatibility with the intended coating process. The product sheet does not state a rated load or a spray-booth certification.
Technical Specifications
| Specification | Value |
|---|---|
| Brand / Model | SOLARY / PS104U |
| Height range | 103–140 cm |
| Rotation | 90° |
| Locking positions | 5 |
| Material thickness | 2.20 mm |
| Casters | Four 4-inch industrial swivel casters |
| Illustrated overall span | 146 cm |
| Illustrated inner span | 86 cm |
| Other illustrated frame dimensions | 90 cm; 98 cm |
| Illustrated base dimensions | 72 × 61 cm |
| Net weight | 12.7 kg |
| Gross weight | 14.1 kg |
| Package size | 96 × 86 × 13 cm |
Model Selection
Choose PS104U for a bumper-specific rotating arrangement with five locking positions. Compare PS104XT for an X-frame support with a junction locking plate or PS104X for a padded mobile X-frame stand. Their positioning mechanisms and published dimensions differ.
FAQ
How far does PS104U rotate?
The supplied model sheet states 90-degree rotation.
How many locking positions are provided?
Five locking positions are stated. Confirm correct engagement and use in the model manual.
What is the height range?
The drawing labels 103–140 cm.
Are the contact areas protected?
Rubber protection is specified at key bumper-contact areas.
What packing and weight figures are listed?
Net weight is 12.7 kg, gross weight 14.1 kg and package size 96 × 86 × 13 cm.
Request a Quote
For workshop procurement, distributor supply or a bulk equipment enquiry, send PS104U quantity, intended components or tools, expected loads and delivery country. Request a SOLARY quotation or browse Tool Racks.
